DIN 6926 M10 Hexagon Flange Nut in Stainless Steel and Titanium Fasteners
Supply titanium and Titanium fasteners,titanium bolts,stainless steel bolt,titanium and stainless nuts,stainless steel w
Send your inquiryDESCRIPTION
Basic Info.
Model NO. | M5-M20 |
Transport Package | Carton |
Specification | M5-M20 |
Trademark | RUIYANG |
Origin | China |
HS Code | 8108909000 |
Production Capacity | 50ton/Month |
Product Description
Supply titanium and Titanium fasteners,titanium bolts,stainless steel bolt,titanium and stainless nuts,stainless steel washers,titanium bicycle nuts,grade various,good price
DIN6926 Hexagon Nuts Flange Nuts:
M5 | M6 | M8 | M10 | M12 | M14 | M16 | M20 | ||
d | - | - | M8x1 | M101x1.25 | M12x1.5 | M14x1.5 | M16x1.5 | M20x1.5 | |
- | - | - | (M10x1) | M12x1.25 | - | - | - | ||
P ¹) | 0.8 | 1 | 1.25 | 1.5 | 1.75 | 2 | 2 | 2.5 | |
c | 1 | 1.1 | 1.2 | 1.5 | 1.8 | 2.1 | 2.4 | 3 | |
da | min | 5 | 6 | 8 | 10 | 12 | 14 | 16 | 20 |
max | 5.75 | 6.75 | 8.75 | 10.8 | 13 | 15.1 | 17.3 | 21.6 | |
dc | max | 11.8 | 14.2 | 17.9 | 21.8 | 26 | 29.9 | 34.5 | 42.8 |
dw | min | 9.8 | 12.2 | 15.8 | 19.6 | 23.8 | 27.6 | 31.9 | 39.9 |
e | min | 8.79 | 11.05 | 14.38 | 16.64 | 20.03 | 23.36 | 26.75 | 32.95 |
m | max | 5 | 6 | 8 | 10 | 12 | 14 | 16 | 20 |
min | 4.7 | 5.7 | 7.6 | 9.6 | 11.6 | 13.3 | 15.3 | 18.9 | |
m1 | min | 2.2 | 3.1 | 4.5 | 5.5 | 6.7 | 7.8 | 9 | 11.1 |
s | Nominalsize=max | 8 | 10 | 13 | 15 | 18 | 21 | 24 | 30 |
min | 7.8 | 9.78 | 12.73 | 14.73 | 17.73 | 20.67 | 23.67 | 29.67 | |
r | max | 0.3 | 0.36 | 0.48 | 0.6 | 0.72 | 0.88 | 0.96 | 1.2 |
Standard:ASME/ANSI B 18.2.1,IFI149,DIN931,DIN933,DIN558, DIN601,DIN960, DIN961, ISO4014,ISO4017Grade:TA1,TA2,TA3,TA5,TA6,TA7,TA9,TA10,TB2,TC3,TC4,TB2,Gr1,Gr2,Gr3, Gr5, Gr7, Gr12etc
Material:Alloy Steel,Stainless Steel,Titanium alloy
Size:various ad typeMinimumOrder:according to customer demandsoonest deliverysea-worthy packagePacking:bulk in cartons (25kg Max.)+wood Pallet or according to customer special demandApplication:Structural Steel; Metal Buliding; Oil&Gas;Tower&Pole; Wind Energy; Mechanical Machine; Automobile: Home DecoratingBicycle,Motorcycle,MedicalIndustry,Surgicalimplants,Chemicalindustry,Aerospace,Spaceflight,Airplane,Ship,Auto,Cars,Wheelchair,Sports,Military etc.
We need more detail as follow. This will allow us to give you an accurate quotation.
Before offer the price,get the quote simply by completing and submitting the form below:
Product:________
Measure: _______ all (Inside Diameter) x_______(Outside Diameter)x_______(Thickness)
Order Quantity: _________________pcs
Material: ____________
When do you need it by? ___________
Where to Shipping: _______________
Email your drawing.
At the same time, we can also provide carbon steel and alloy steel stud bolts.
Transportation:
If you are interested in our products, please take action to purchase or wholesale high quality Stainless steel and Titanium fastener, stainless steel bolt, titanium bolt,stainless steel nut,titanium alloy nut,titanium screws, stainless steel and titanium gasket,from our factory for sale.Shaanxi Ruiyang, as one of the leading manufacturers and suppliers in China, has competitive price for you to choose!
